Single Mode Fiber Jumper
FC-FC Single Mode Patch Cord
The FC-FC fiber patch cords include simplex FC-FC cables and duplex FC-FC cables with PVC, LSZH and PE jacket. There are PC, UPC or APC polishing types optional. All Patch Cords are compliant with RoHS. We supply related standard and customized fiber jumpers with competitive price and prompt delivery.
-
l Low insertion loss and high return loss
l Telcordia, IEC, TIA/EIA standard compliant
l RoHS compliant
l 100% optical performance inspection and end face geometric
l Varieties of cable assemblies
l Suitable for high-speed, high-capacity optical fiber transmission system
-
Parameter
SM
MM
UPC
APC
UPC
Insertion Loss（dB）
≤0.2
≤0.3
≤0.2
Return Loss（dB）
≥50
≥60
≥35
Repeatability（dB
≤0.1
Interchangeability（dB）
≤0.2
Plug times（times）
≥1000
Tensil Strength（N)
≥100
Durability（dB）
≤0.2
Operating temperature（℃
-45~+75
Storage temperature（℃）
-45~+85
-
l Telecom, datacom
l Optical fiber communications system
l Optical fiber access networks
l Optical fiber test equipements
l FTTX+LAN
l Optical fiber CATV
